업계 최고의 데이터 무결성 및 신뢰성을 특징으로하는 Higgs™9 은
최근 복잡한 어플리케이션 및 진화하는 IoT 정보 데이터에 맞게 설계된 최첨단 읽기 / 쓰기 감도 및 유연한 메모리 용량을 제공합니다.
| Features | Benefits | Description |
|---|---|---|
 | Detects and fixes single bit errors and flags dual bit errors. | Safeguarded data and immunity to typical sources of single bit errors (chip damage, low power etc.) |
| Read sensitivity | Up to -22.5 dBm | Allows smaller tags to be designed or larger read & write distances to be realized. |
| Write sensitivity | Up to -19 dBm | |
| Best in class memory reliability | 200,000 write cycles | Robust memory retention (twice that of competition |
| 96-bit expandable EPC | Supports EPC size up to 496b for flexibility | Additional 400 bits allows storing of larger identifying information |
| 688 bit user memory | User memory for storage of additional application data. | For applications requiring data beyond EPC (asset data, service history, usage info etc.) |
| 48b UTID with lower 38b unique serial for SGTIN generation | 48b UTID. Lower 38b are duplicated in the EPC for SGTIN generation. | For retail and general serialzation |
| Larger “pads” for improved antenna connectivity | More contact area for antenna connectivity | Increased and more consistent yield inlay to inlay |
